Researchers have developed high-power fuel cells that operate at double the voltage of conventional hydrogen fuel cells.
Electrification of the transportation sector—one of the largest consumers of energy in the world—is critical to future energy and environmental resilience.
Electrifying transportation will require high-power fuel cells (either stand alone or in conjunction with batteries) to facilitate the transition to electric vehicles, from cars and trucks to boats and airplanes.
Liquid-fueled cells are an attractive alternative to traditional hydrogen fuel cells because they eliminate the need to transport and store hydrogen.
They can help to power unpiloted underwater vehicles, drones, and, eventually, electric aircraft—all at significantly lower cost.
They could also serve as range-extenders for current battery-powered electric vehicles, thus advancing their adoption.
The research appears in the journal Cell Reports Physical Science.
The researchers have pioneered a reactant: identifying an optimal range of flow rates, flow field architectures, and residence times that enable high power operation.
This approach addresses key challenges in direct borohydride fuel cells (DBFCs), namely proper fuel and oxidant distribution and the mitigation of parasitic reactions.
Importantly, the team has shown a single-cell operating voltage of 1.4 or greater, double that obtained in conventional hydrogen fuel cells, with peak powers approaching 1 watt/cm2.
Doubling the voltage would allow for a smaller, lighter, more efficient fuel cell design, which translates to significant gravimetric and volumetric advantages when assembling multiple cells into a stack for commercial use.
Their approach is broadly applicable to other classes of liquid/liquid fuel cells.
“The reactant-transport engineering approach provides an elegant and facile way to significantly boost the performance of these fuel cells while still using existing components,” says Vijay Ramani, professor at the McKelvey School of Engineering at Washington University in St. Louis.
“By following our guidelines, even current, commercially deployed liquid fuel cells can see gains in performance.”
The key to improving any existing fuel cell technology is reducing or eliminating side reactions. The majority of efforts to achieve this goal involve developing new catalysts that face significant hurdles in terms of adoption and field deployment.
“Fuel cell manufacturers are typically reluctant to spend significant capital or effort to adopt a new material,” says Shrihari Sankarasubramanian, a senior staff research scientist on Ramani’s team. “But achieving the same or better improvement with their existing hardware and components is a game changer.”
“Hydrogen bubbles formed on the surface of the catalyst have long been a problem for direct sodium borohydride fuel cells, and it can be minimized by the rational design of the flow field,” says Zhongyang Wang, a former member of Ramani’s lab who earned his PhD in 2019 and is now at the Pritzker School of Molecular Engineering at the University of Chicago.
“With the development of this reactant-transport approach, we are on the path to scale-up and deployment.”
“We are at the stage of scaling up our cells into stacks for applications in both submersibles and drones,” Ramani says.
The technology and its underpinnings are the subject of patent filing and are available for licensing. The US Office of Naval Research funded the research.
Written by Vijay Ramani, Shrihari Sankarasubramanian and Zhongyang Wang.
