A “sole” mate to prevent diabetic foot ulcers

Credit: CC0 Public Domain

In a new study, researchers have developed a new cooling insole to reduce the foot temperature of patients with diabetic neuropathy by several degrees, diminishing a big risk factor for diabetic foot ulcers.

This new device could eventually prevent thousands of amputations that take place worldwide each year because of this condition.

The research was conducted by UT Southwestern scientists.

Just in the U.S., more than 100,000 lower extremity amputations take place every year, many of them prompted by diabetic foot ulcers.

These ulcers are linked to numerous quality-of-life and health consequences, including a mortality rate of 50 percent within five years for patients who develop them.

Although the exact cause of this common diabetes complication is unclear, high foot pressure has long been considered a prevailing cause.

Consequently, the most prescribed preventive treatment for diabetic foot ulcers is pressure-relieving insoles.

However, this prophylactic intervention isn’t accomplishing its goal, since diabetic amputation rates have been on the rise despite widely available pressure-relieving insoles.

About 30% to 40% of patients who have had one diabetic foot ulcer will still develop another within a year.

Hoping to decrease these numbers, the team focused on another risk factor for these ulcers: foot temperature.

Animal studies have shown that skin maintained between 25 and 30 degrees C is less likely to break down under pressure than the skin at higher temperatures.

The feet of diabetic patients already tend to be warmer due to inflammation associated with the disease, compounded by friction from walking and the stiff therapeutic shoes that patients wear, which are usually made of synthetic materials that act as heat insulators.

In the study, the team developed a system that circulates cool water into pressure-relieving insoles.

The device, named Temperature and Pressure Monitoring and Regulating Insoles (TAPMARI), consists of a small box strapped to the wearer’s calf that houses a cooling unit, a small water pump, a battery pack, and a thermostat.

The cooling unit harnesses a type of thermoelectric cooling called the Peltier effect to chill water to the desired temperature that’s then pumped into insoles placed in the wearer’s shoes.

The researchers tested the improved device in eight volunteers: one man and seven women of a median age of 45 years. Five of these volunteers were healthy and three had diabetic neuropathy.

Using an infrared thermal camera, the researchers took photos of the subjects’ feet at baseline before wearing the insoles, then placed a cooling insole in only their right shoes.

They took more thermal photos after the people walked five minutes on a treadmill and again after they wore the insoles an additional two hours and walked five minutes on the treadmill again.

Results showed that the mean foot temperature in the group was 28.1 degrees C. Mean foot temperatures at the end of the study were 31.7 degrees C for the left foot and 25.9 degrees C for the right, which was cooled by TAPMARI.

Although the diabetics’ feet got warmer than those of the healthy volunteers during walking, they still maintained a mean temperature of 27.5 degrees C in the right foot.

This suggests that the insoles could maintain the temperature in a range that protects against skin breakdown.

Cool temperatures from the insoles didn’t cause vasoconstriction (narrowing of blood vessels) in the foot, which could have damaged tissue.

However, sole temperatures reached as high as 30.8 degrees C in some regions of the cooled feet, particularly in the midfoot, suggesting that the design of the insole needs to be improved.

Other design elements could also be tweaked, he says, such as reducing the size of the unit worn on the calf.

Eventually, these devices could change the course for patients with diabetes, preventing this common and often serious complication.

One author of the study is Metin Yavuz, D.Eng., an associate professor in the School of Health Professions’ Division of Prosthetics.

The study is published in The Journal of Foot & Ankle Surgery.
